E-3 R CRANKCASE COVER
　

E-3 R CRANKCASE COVER
NO Part No Description Reqd No PRICE NOTES
93 94
1 11340-NF4-780 COVER COMP R CRANK CASE 1 1 ¥18,500 -
2 11394-NF4-610 GASKET R COVER 1 1 ¥420 -
3 15611-ND5-000 CAP OIL FILLER 1 - ¥250 -
　 15611-NF4-900 CAP OIL FILLER - 1 ¥250 -
4 90134-ND5-000 BOLT FLANGE 6*10 1 1 ¥60 -
5 90543-273-000 PACKING FRONT FORK DRAIN COCK 1 1 ¥90 -
6 91304-MJ0-003 O-RING 1 1 ¥105 -
7 94301-08140 PIN DOWEL 8*14 2 2 ¥60 -
8 96001-06032-07 BOLT FLANGE SH 6*32 6 6 ¥50 -
9 96001-06040-07 BOLT FLANGE SH 6*40 1 1 ¥50 -
