| NO |
PART NO |
DESCRIPTION |
01 |
02 |
PRICE |
REMARKS |
| 1 |
18310-NXA-000 |
EXPANSION CHAMBER COMP,.NO1 |
1 |
1 |
65,000 |
|
| 2 |
18320-NXA-000 |
EXPANSION CHAMBER COMP,.NO2 |
1 |
1 |
65,000 |
|
| 3 |
18326-NXA-710 |
STAY, CHAMBER |
1 |
1 |
600 |
|
| 4 |
18330-NXA-000 |
SILENCER ASSY., R |
1 |
1 |
15,500 |
|
| 5 |
18332-KS6-000 |
SPRING, EXHAUST PIPE |
4 |
4 |
350 |
|
| 6 |
18332-NXA-000 |
INNER COMP., SILENSER |
2 |
2 |
7,300 |
|
| 7 |
14539-KCZ-300 |
TUBE, TENSIONER SPRING |
(4) |
4 |
175 |
|
| |
18333-ND4-760 |
TUBE, SPRING |
4 |
- |
470 |
|
| 8 |
18334-KA3-830 |
RUBBER, SILENCER |
2 |
2 |
155 |
|
| 9 |
18336-KS6-700 |
COLLAR, SILENCER MOUNT |
2 |
2 |
245 |
|
| 10 |
18336-NF5-761 |
GLASS WOOL, L |
2 |
2 |
1,250 |
|
| 11 |
18340-NXA-000 |
SILENCER ASSY., L |
1 |
1 |
15,500 |
|
| 12 |
18344-NXA-300 |
BODY, SILENCER |
2 |
2 |
7,200 |
|
| 13 |
90506-430.-000 |
WASHER, FENDER MOUNT |
2 |
2 |
145 |
|
| 14 |
91081-NF4-003 |
RIVET, BLIND, 3.2 |
16 |
16 |
10 |
|
| 15 |
91301-KR3-003 |
O-RING, 25.5*2.5 |
1 |
1 |
160 |
|
| 16 |
91301-MW4-004 |
O-RING, 26.2*1.9 |
2 |
2 |
95 |
|
| 17 |
91315-KE8-003 |
O-RING, 24*3 |
1 |
1 |
140 |
|
| 18 |
94050-06000 |
NUT, FLANGE, 6mm |
1 |
1 |
35 |
|
| 19 |
96500-06025-00 |
BOLT, FLAMGE, DR, 6*25 |
2 |
2 |
50 |
|
| 20 |
96700-06016-07 |
BOLT, SOCKET, 6*16 |
6 |
6 |
40 |
|
|
